Polyurethane Fine Screen Mesh High Frequency ( PU Fine Screen , Urethane Fine Screen )

Polyurethane Fine Screen also Be Named As Polyurethane Fine Sieve.
The Materials Can Be Choose As Polyurethane ( PU , Urethane )
Our Company Can Produce Fine Screen Or Sieve As Panels , Mesh , Sheet , Plate , Mats , Deck , Cloth , Media , Bends .
High Frequency Polyurethane Fine Screen Mesh Is The Core Component Of Fine Screen Vibration Screen. It Directly Affects The Screening Efficiency And Performance. Our Patented One-In-One Shaping Screen Has Longer Surface Life, Blindness Prevention And No Leakage. It Improves The Mineral Recovery And Is Widely Used In The Processing And Application Of Metal And Non-Metal Minerals.
Fine Screen Specification
Screen Size: 1045x700mm
Opening Size Is 0.075
Normal Service Life: 6-12 Months
Material: Polyurethane Material
High Frequency Vibrating Screen-Stacker
Features
High Opening Area 32%-42%
Fiber Reinforced Integrated Forming Technology To Prevent Cracking And Improve Tensile Strength And Service Life Of Screen
Anti-Glare Taper Aperture Design Improves Screening Performance And Efficiency
Used In Mineral Processing And Application
Our Separate Polyurethane Screen Is The Right Choice For Your Existing Fine Screening Machine. If You Are Looking For Customized Pu Fine Screen, Please Contact Us. We Are Happy To Help You.
Pu Fine Screen Mesh For Ore And Coal Sieveing
Mini Aperture:0.15mm
High Opening Rate
Aperture Width(mm):0.10,0.12,0.15,0.18,0.2,0.3,0.4,0.5,0.7,1.0,
Aperture Length(mm): 2.12 ,2.59 ,2.75 ,4.30  ,5.75
Opening Rate: 25-30%
Life-Span:  6 Months
Outer Dimensions: Nominal Width(mm): 600,800,1000,1200,1400,1600
Nominal Length (mm):700,800,1000,1200,1500,2000,2500,3000,3500
Depending On The Installation Requirements, Both Ends Of Mesh Can Be Made With Hook Or Without Hook.
Advantages Of Polyurethane Fine Screen
1. Long Service Life And Large Bearing Capacity. Because Polyurethane Elastic Sieve Plate Uses Steel Wire Rope As Skeleton Material, And Polyurethane Itself Has Very High Elastic Modulus, High Strength To Absorb Impact Force, High Wear Resistance, So It Has High Tensile Strength, And Its Bearing Capacity Is More Than 2.5 Times That Of Rubber Sieve Plate. Its Service Life Is 8-10 Times Longer Than That Of Ordinary Metal Sieve Plate, 3 Times As Much As That Of Stainless Steel Sieve Plate And 3.9 Times As Much As That Of Natural Rubber. It Is The Best Wear-Resistant Sieve Material In The World. Polyurethane Sieve Plate Is a Kind Of Polymer Organic Elastomer With Excellent Abrasion Resistance, Flexibility Resistance And High Load-Carrying Capacity. The Raw Material Of Polyurethane Sieve Plate Has Been Specially Treated To Ensure That It Never Delaminates Under Long-Term Alternating Load.
2. Screening Efficiency Is High. The Inner Self-Cleaning Performance Of The Screen Surface Is Not Blocked And The Screening Efficiency Is High. Because Polyurethane Has Strong Water Permeability And Large Cone Angle Of Sieve Hole (140 Degrees), It Can Effectively Prevent The Adhesion Of Wet Fine Particles, So It Is Suitable For Screening And Grading Of Wet Fine Particles. The Polyurethane Sieve Plate In Our Factory Uses Imported Raw Materials, Its Elastomer And Good Relaxation Performance Can Effectively Avoid Blocking In Dynamic Conditions.
3. Wide Scope Of Application, Stronger Professional Applicability, Applicable To Any Type Of Vibrating Screen Machine And The Production Of Measuring Mechanism. Polyurethane Sieve Plate Is Specially Used In Hydropower Stations, Building Materials And Other Metal Mineral Processing. The Screening Efficiency Of All Kinds Of Materials In The Range Of 0.1mm-170mm Is Not Affected By Dry And Wet Screening. The Advantages Of Polyurethane Sieve Surface Are More Fully Demonstrated For Dehydration And Desorption Sieve In The Range Of 0.5m-3mm. The Product Is Water-Resistant, Corrosion-Resistant, Aging-Resistant, Easy To Replace And Maintain. Polyurethane Has Low Density (1.32kg/m 3) And Lighter Weight Than Metal Screen Surface. It Can Reduce The Unit Consumption Of Production, So It Can Meet The Requirements Of Large-Scale Development Of Screen Machine.
4. High Screening Accuracy. The Production Process Of Polyurethane Sieve Plate Is Mold Casting Process, With Accurate Pore Size And High Screening Quality. The Particle Size Of Sieve Material Can Well Meet The Requirements Of Users. Simple Installation, Easy Replacement And Maintenance, This Product Is Suitable For Any Type Of Screening Machine, Light Weight, For Site Installation Or Replacement And Maintenance, Greatly Reducing The Workload.
5. Low Working Noise, Meeting The Environmental Noise Standards Of National Specifications. According To The Actual Measurement, The Same Screen Machine Using Polyurethane Sieve Plate Than Metal Sieve Plate Can Reduce Noise By 5 - 20 Decibels, And Greatly Reduce Dust Flying, So That The Production Site Has a Quiet And Clean Working Environment.

6. Significant Economic Benefits. Although The Price Of Polyurethane Fine Screen Surface Is Higher Than That Of Metal Sieve Plate, If The Factors Such As Screening Efficiency, Maintenance Cost And Service Life Are Considered Comprehensively, The Overall Benefit Of Polyurethane Rubber Sieve Surface Is Much Better Than That Of Ordinary Metal Sieve Surface. According To The Survey, 45 Tons Of Steel Can Be Saved Per Ton Of Polyurethane Rubber Sieve Plate. More Than 40,000 Yuan Will Be Saved For Maintenance. Therefore, Polyurethane Sieve Surface Instead Of Steel Sieve Surface Will Be The Inevitable Choice Of The Vast Majority Of Enterprises In The Future.
